Product description:

 The advantage of FU Series Chain Conveyor oringinates from its principle of work. Materials have the properties of internal friction and side pressure, and the movement of chains makes internal pressure of materials and internal friction of grains increase in the trough. When internal friction among material layers is more than external friction between materials and trough wall, materials will flow forwardly along with chains like water. When the specific value between material layers’ height and trough’s width satisfies certain conditions, stable materials flow can be formed. Advanced principle, good design and manufactural technology ensure the excellent properties of this serial products.

Application:

This machine is widely used in non-ferrous mines, cement, chemical and metallurgy transport, transport, mixing process, continuous production process indispensable link, can be in the open air and humid environment to work reliably.

Features ：

1.Powder or fine grained balk cargo can be transported horizontally or with less than or equal to 30’angle of inclination.

2.It has good capacity,which can reach 15-600 m3／h.

3.It has long transporting distance, and the maximum of single conveyor can reach about 60m.

4.The power comsumption is low, it can reduce 40%-60% in comparision with screw conveyor.

5.Omniseal casing is semlessly for dust. It’s safe to operate it . It’s reliable for environment.

6.It has long lifetime. Normal lifetime of chains is more than 5 years, and the lifetime of rollers is equal or more than 2 or 3 years.

7.It can transport in two-way, and also can be arranged on the gantry, ground and pit.

8.It’s flexible to feed and discharge in multi-point and technical arrange.

9.The operating cost and maintain rate is low.

                                               Technical parameters：
