MS buried scraper conveyor
| Item No.: | IFA-ZRD024150 |
Product overview:
MS buried scraper conveyor is a closed rectangular shell, by means of moving the scraper chain conveyor shape of powder, small grains and small pieces of bulk material such as continuous conveyor equipment. Because at the time of conveying material, scraper chain all buried in the material, so called "buried scraper conveyer.
Main features:
1、 Simple structure, light in weight and small size, good sealing, convenient installation and maintenance.
2、 Not only can level but also be inclined and vertical transportation; not only can single machine conveyor, and could combine to decorate, concatenated.
3、 Can loading more, also can multipoint discharge, process arrangement is more flexible
4、 Due to the closed shell, when conveying material can greatly improve the working conditions, prevent environmental pollution.
Main parameters
|
Model number |
F1 |
f |
f1 |
H |
H1 |
-H2 |
H3 |
H4 |
h |
h1 |
h2 |
J |
|
MS16 |
150 |
88 |
650 |
289.0 |
470 |
440 |
450 |
261 |
100 |
161 |
60 |
350 |
|
MS20 |
150 |
108 |
700 |
329.0 |
530 |
480 |
530 |
296 |
100 |
196 |
80 |
420 |
|
MS25 |
150 |
128 |
750 |
389 |
630 |
540 |
660 |
346 |
100 |
246 |
100 |
510 |
|
MS32 |
230 |
168 |
1070 |
572.0 |
764 |
723 |
820 |
408 |
100 |
308 |
150 |
670 |
|
MS40 |
230 |
198 |
1070 |
612.5 |
764 |
763 |
860 |
408 |
100 |
308 |
150 |
800 |
|
Model number |
B |
B1 |
B2 |
B3 |
B4 |
b |
t |
C |
D |
d |
d1 |
F |
|
MS16 |
160 |
410 |
260 |
305.5 |
510 |
16 |
58.5 |
0 |
258.69 |
80 |
55 |
390 |
|
MS20 |
200 |
510 |
300 |
268.5 |
610 |
20 |
74.2 |
0 |
324.01 |
95 |
70 |
410 |
|
MS25 |
250 |
600 |
350 |
425.5 |
700 |
24 |
90.0 |
0 |
412.86 |
110 |
85 |
440 |
|
MS32 |
320 |
800 |
420 |
495.0 |
900 |
32 |
116.5 |
130 |
514.76 |
135 |
110 |
650 |
|
MS40 |
400 |
890 |
500 |
578.0 |
990 |
36 |
137.2 |
150 |
514.76 |
160 |
130 |
650 |
